aluminum profile packing line

Automatic aluminum Packing line
No Detail Spacification
Jinglin
1 Sub-bundle strapping machine 1 Set 4 pcs
 – size max W110mm x H90mm x L6400mm
min W60mm x H60mm x L6100mm
 -weight 10-100 kg
 -speed adjuting regulation by inverter
 -Ring speed 20-110 rpm
 -Wrapping material Stretch film
W 60-100mm , ID 50 mm, OD 100-150 mm
2 LOADING BELTS
 -BELTS TYPE POLYESTER
 -BELTS WIDTH 50 mm
 -NUMBER OF BELTS 5 4 belts
 -MAX – MIN PROFILE
LENGTH
6400/6100 mm We would like to change the minimum Profile length to be 4000mm , can do it or not?
 -DRIVE Electric moter
 -SPEED VARIABLE
CONTROLLED
BY
INVERTER
 -CONSTRUCTION FEATURE steel
 -MOTION controlled automatically,
movement by pneumatic cylinder.
 -OPERATION Automatic belts and Automatic Feed Roller
3 IN FEED ROLLER CONVEYOR
 -TYPE ROLLER
CONVEYOR
 -ROLLERS POLYURETHANE
POWERED
ROLLER
 -ROLLER
CONVEYOR
LENGTH
Please advise. 7500mm
 -ROLLERS
WIDTH
Please advise. 250mm
 -ROLLERS
HEIGHT
Please advise. app.900mm
 -ROLLERS
Ø
Please advise. 45mm
 -MAX
/
MIN
PROFILE
LENGTH
Please advise. 4000-6500mm
 -PROFILE
WIDTH/HEIGHT
Please advise. W:60-150mm
 -DRIVE Please advise. Motor
 -CONSTRUCTION FEATURE steel
 -MOTION controlled automatically,
 -OPERATION Roler speed control by inverter
 –
4 Sub-bundle wrapping machine
 – size profile length max W200mm x H100mm x L6400mm
min W100mm x H30mm x L6100mm
Outer packing diameter 55-142
 -weight 10-100 kg
 -speed 20-35s/sub-bundle
 -Ring speed 20-100  rpm
 -Wrapping material Stretch film can we also use the PAPER and PLASTIC? Please specify the wrapping material that we can use for this machine.
W 60-100mm , ID 50 mm, OD 100-150 mm
 – Paper Size (Gold star) ID 45 , OD 250, W 115 mm
 – Drive power
5 Automatic Tape Sealing machine
 – Tape material BOPP adhesive tape
W 80 mm , ID 76 mm, OD 100-150 mm
(special size is available)
6 OUT FEED ROLLER TABLE
 -TYPE ROLLER
CONVEYOR
 -ROLLERS Please advise. Steel roller
 -ROLLERS
WIDTH
Please advise. 250mm
 -ROLLERS
Ø
Please advise. 45mm
 -MAX
/
MIN
PROFILE
LENGTH
Please advise. W:60-150mm
 -DRIVE Please advise. MOTOR
 -SPEED Please advise. 6-13m per minute
 -CONSTRUCTION FEATURE steel
Please advise.
 -MOTION Please advise. Motor+chain
 -OPERATION Please advise. Automatic
 –
7 CONTROL PANEL
 -Electrical cabinet PLC and HMI control system
8 Power voltage: 380V, 3phase, 50Hz
9 Brand Main Part Lite
 -PLC Siemens
 -Touch screen Siemens
 -Frequency converters Siemens
 -Motor Dongli
 -Cylinder Airtac
 -Photoelectric sensor Autonics
 -Switch Schneider
 -Power supply Please advise. 380v 3p 50Hz
 -Contactor Schneider
 -Main circuit breakers AC Please advise. Sechneider
 -Automatic circuit breakers Please advise. Sechneider
 -Servo Drive Please advise. Not servo motor
 -Motor circuit breakers Please advise. Sechneider
 -Linear encoders Please advise. Delta/omrom
 -Rotary encoders Please advise. Not enconder for rotary, we choose sensor for checking the ring totary
 -Rail Guides Please advise. LY
